AUS-SPEC Urban and open spaces

AUS-SPEC Urban and open spaces covers planning and design, tendering and contract preliminaries, construction, maintenance and operations of urban and open spaces. It also includes the NATSPEC BUILDING Landscape package.

$1430 + GST

Intended use

Project types
Planning, design, construction and maintenance of local government assets including:

Excludes the following specialist maintenance activities:

Size and complexity
Landscaping of all complexities

Project types
Environmental Services, Recreation and Maintenance Managers and Park Superintendents

Inclusions

Worksections included in Urban and open spaces

0010 Quality requirements for design
This worksection Template is a framework for the development of request for tender documents based on AUS SPEC worksections. It includes a cover page and sets out the documents required for Part A Tender information and Part B Contract documentation volumes.

0012 Waterfront development
This worksection Template is applicable to the design of waterfront development structures such as marinas, wharfs, jetties, boat tramps and seawalls and the design of artificial waterways.

0013 Bushfire protection (Design)
This worksection Template is applicable to the design of bushfire protection facilities.

0021 Site regrading
This worksection Template is applicable to site regrading for both Council works and land development and subdivision approved by Council.

0022 Control of erosion and sedimentation (Design)
This worksection Template is applicable to the design and documentation requirements of control measures for mitigating the effects of erosion and sedimentation from construction activities and stormwater run-off, as required for the development erosion and/or sediment risk level. It includes both temporary and permanent control measures.

0044 Pathways and cycleways (Design)
This worksection sets Template out requirements to be used in the design of various types of cycleways and pathways.

0120 Pre-tendering contract preparation (AUS-SPEC)
This worksection Template is a framework for the development of request for tender documents based on AUS SPEC worksections. It includes a cover page and sets out the documents required for Part A Tender information and Part B Contract documentation volumes.

0121 Tendering
This worksection Template reflects the principles of the main Australian codes of practice, including AS 4120 which is cited in a number of state government’s codes of practice. The worksection assumes head-contract tendering. It is applicable to non-contractual material and so does not form part of the contract documents.

0122 Information for tenderers (AUS-SPEC)
This worksection Template is applicable to an introductory document to enable prospective Tenderers to determine whether the scope and type of works in the proposed Contract is within their capability. It is a separate document to, but aligned with, 0123 Conditions of tendering.

0123 Conditions of tendering (AUS-SPEC)
This worksection Template is applicable to conditions of tendering including contract information, tender submission requirements, tender evaluation and selection criteria. It assumes traditional paper-based tendering methods but this worksection can be adapted to suit digital distribution and eTendering (electronic tendering system). If using eTendering, consult with the administrators of the system about the standard forms provided as part of the system and about amending these to suit your requirements. The worksection should align with 0122 Information for tenderers, a separate, introductory document for prospective Tenderers. This worksection does not form part of the contract documents.

0124 Tender submission documents (AUS-SPEC)
This worksection Template is applicable to the returnable forms and schedules nominated by the Principal for completion by the Contractor for inclusion in the Tender submission. The completed worksection forms VOLUME 4 -Tender Submission Documents of the request for tender (RFT). It assumes traditional paper-based tendering methods but this worksection can be adapted to suit digital distribution and eTendering (electronic tendering system). If using eTendering, consult with the administrators of the system about the standard forms provided as part of the system and about amending these to suit your requirements.

0125 Standard contract checklists (AUS-SPEC)
The following worksection applies to standard contracts and provides checklist for contract compilation, tender preparation, receipt of tenders and tender assessment.

0126 Period supply and service checklists (AUS-SPEC)
This worksection applies to period supply and service contracts and provides a checklist for commissioning of documentation, determination of technical requirements, document finalisation approval and the tender advertisement template.

0131 Preliminaries (Generic)
This worksection Template is applicable to the site requirements of the owner and allows for the selection of a contract. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, owner’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, owner-supplied items, separate contracts, some aspects of payment for the works, and pest eradication.

0131b Preliminaries
This worksection Template is applicable to the site requirements of the owner and allows for the selection of a contract. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, owner’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, owner-supplied items, separate contracts, some aspects of payment for the works, and pest eradication.

0134 General requirements (Supply) (AUS-SPEC)
This worksection Template is applicable to the general requirements for a supply contract and includes the supply of labour, materials and plant to carry out the works. This worksection can be used for minor construction works. For major construction works use 0136 General requirements (Construction).

0135 General requirements (Service) (AUS-SPEC)
This worksection Template is applicable to the general requirements for a supply and service contract. The work under this contract comprises of supply of labour, materials and equipment necessary to carry out the services specified. It can be used for a single contract for provision of general goods and services over a period of time.

0136 General requirements (Construction) (AUS-SPEC)
This worksection Template is applicable to the site requirements of the Principal for construction projects. It includes a project description, work not in the contract, site investigations, signage, survey control, environmental planning, noise and vibration controls, utilities and authorities and site facilities.

0138 Multiple contracts
This worksection Template is applicable to projects to be let as several prime contract packages, also known as separate contracts and trade package contracts. It deals with the interfaces between the contracts and provides a framework for scheduling the boundaries of responsibility between the contractor and the principal or other contractors, on behalf of the principal. It is recommended to read NATSPEC TECHnote GEN 003 for Guidance and information before using this worksection.

0140 Preliminaries – ABIC BW 2018 C
This worksection Template is applicable to the ABIC BW 2018 C contract for small commercial projects or single trade activities where an architect administers the contract, applicable in all states and territories. It is relevant to the site requirements of the owner. The project specific version may include site security arrangements, adjoining property constraints, occupancy constraints, owner’s temporary facilities, project signage, authority requirements, survey requirements, owner-supplied items, and pest eradication.

0141 Preliminaries – ABIC MW-2008
This worksection Template is applicable to the ABIC MW-2008 contract for major non-housing work. It can be adapted for use with the various state and territory specific contracts for housing work. It is relevant to site requirements of the owner. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, owner’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, owner-supplied items, separate contracts, some aspects of cost adjustment, and pest eradication.

0141 Preliminaries – ABIC MW-2018
This worksection Template is applicable to the ABIC MW-2018 major works contract for non-housing work. It can be adapted for use with the various state and territory specific contracts for housing work. It is relevant to site requirements of the owner. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, owner’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, owner-supplied items, separate contracts, some aspects of cost adjustment and pest eradication.

0142 Preliminaries – ABIC SW-2018
This worksection Template is applicable to the ABIC SW-2018 simple works contract for non-housing work. It can be adapted for use with the various state and territory specific contracts for housing work. It is relevant to the site requirements of the owner. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, owner’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, owner-supplied items, separate contracts, some aspects of cost adjustment and pest eradication.

0142 Preliminaries – ABIC SW-C Qld
This worksection Template is applicable to the ABIC MW-2011 C QLD simple works contract for non-housing work. Simple works for housing in Queensland is covered by ABIC MW-2011 H QLD. It is relevant to the site requirements of the owner. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, owner’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, owner-supplied items, separate contracts, some aspects of cost adjustment, and pest eradication.

0143 Preliminaries – AS 2124
This worksection Template is applicable to the AS 2124 building contract for major works. It is relevant to the site requirements of the principal. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, principal’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, principal-supplied items, separate contracts, some aspects of cost adjustment, and pest eradication.

0144 Preliminaries – AS 4000
This worksection Template is applicable to the AS 4000 building contract for major works. It is relevant to the site requirements of the principal. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, principal’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, principal-supplied items, separate contracts, some aspects of cost adjustment, and pest eradication.

0145 Preliminaries – AS 4905
This worksection Template is applicable to the AS 4905 building contract for minor works. It is relevant to the site requirements of the principal. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, principal’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, principal-supplied items, separate contracts, some aspects of cost adjustment, and pest eradication.

0146 Preliminaries – AS 4902
This worksection Template is applicable to the AS 4902 building contract for design and construct. It is relevant to the site requirements of the principal. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, principal’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, principal-supplied items, separate contracts, some aspects of cost adjustment, and pest eradication.

0147 Conditions of Contract (AUS-SPEC)
This worksection Template is applicable to the General conditions of contract, Annexures to the contract and Special conditions of contract. The completed worksection forms VOLUME 1-Conditions of contract. This worksection is based on AS 2124 General conditions of contract. Amend this document for use with other general conditions of contract, special conditions, OH & S and environmental requirements. See NATSPEC disclaimer on the use of this worksection for this and other contracts.

0148 Preliminaries – ABIC EW-1
This worksection Template is applicable to the ABIC EW-1 contract for early works. It is relevant to the site requirements of the owner. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, separate contracts, some aspects of cost adjustment, and pest eradication.

0149 Preliminaries – NCW4
This worksection Template is applicable to the NCW4 contract for National Capital Works. It is relevant to site requirements of the principal. The project specific version may include site security arrangements, occupancy constraints, adjoining properties constraints, principal’s site office and other temporary facilities, project signage, provisional sums, requirements for progress photographs, authority requirements, survey requirements, principal-supplied items, separate contracts, some aspects of payment for the works and pest eradication.

0152 Schedule of rates (Construction)
This worksection consists of descriptions of quantities required for a schedule of rates for a construction project. The quantities shown are estimated quantities only and are not to be taken as correct quantities of work to be carried out or paid for under the various items of work.

0153 Schedules – Period supply and service
This worksection Template is applicable to the schedule of rates requirements for tenderers for period supply and service (Supply and Deliver) contracts.

0160 Quality
This worksection Template applies to the selection and implementation of a project Quality Management System based on AS/NZS ISO 9001. It includes the submission of a Quality Plan from a contractor having an approved Quality Manual.

0161 Quality management (Construction) (AUS-SPEC)
This worksection Template applies to the selection and implementation of a project Quality Management System based on AS/NZS ISO 9001. It includes the submission of a Quality Plan from a contractor having an approved Quality Manual.

0162 Quality (Supply) (AUS-SPEC)
This worksection Template is applicable to the quality requirements for delivery documentation of a quality assured product where the Producer has third party certification of an implemented quality system conforming to AS/NZS ISO 9001.

0163 Quality (Delivery) (AUS-SPEC)
This worksection Template is applicable to the quality requirements for delivery of products for acceptance by the Principal in accordance with AS/NZS ISO 9001.

0167 Integrated management (AUS-SPEC)
This worksection Template is applicable to the documentation and operation of a system that collects the operating procedures of Quality requirements, Environmental requirements and Work Health and Safety into a single integrated management system.

0171 General requirements
This worksection Template draws together administrative material which is common to the technical worksections for new work, interiors and for alterations and additions, including services. It should therefore be brought to the attention of subcontractors and others using that material. Each technical worksection includes a cross reference to that effect. General requirements cover topics such as referenced documents, interpretation, inspection and tests, samples and contractor’s submissions, materials and components, bushfire resistance, installation, marking and completion.

0171b General requirements
This worksection Template draws together administrative material which is common to the technical worksections for new work, interiors and for alterations and additions, including services. It should therefore be brought to the attention of subcontractors and others using that material. Each technical worksection includes a cross reference to that effect. General requirements cover topics such as referenced documents, interpretation, inspection and tests, samples and contractor’s submissions, materials and components, bushfire resistance, installation, marking and completion.

0171q DEPW (Qld) – General requirements
This worksection Template draws together administrative material which is common to the technical worksections for new work, interiors and for alterations and additions, including services for DHPW (Qld). It should therefore be brought to the attention of subcontractors and others using that material. Each technical worksection includes a cross reference to that effect. General requirements cover topics such as referenced documents, interpretation, inspection and tests, samples and contractor’s submissions, materials and components, bushfire resistance, installation, marking and completion.

0172 Environmental management
This worksection Template is applicable to the environmental management of the building site and includes environmental controls for erosion and sedimentation, flora and fauna, groundwater, indigenous and non-indigenous heritage, traffic, water quality, waste and weeds. It provides for either documentation of requirements for control plans prepared by the contractor or documentation of control measures required by the principal/consultant.

0172b Environmental management
This worksection Template is applicable to the environmental management of the building site and includes environmental controls for erosion and sedimentation, flora and fauna, groundwater, indigenous and non-indigenous heritage, traffic, water quality, waste and weeds. It provides for either documentation of requirements for control plans prepared by the contractor or documentation of control measures required by the principal/consultant.

0172q DEPW (Qld) Environmental management
This worksection Template is applicable to the environmental management of the building site and includes environmental controls for erosion and sedimentation, flora and fauna, groundwater, indigenous and non-indigenous heritage, traffic, water quality, waste and weeds. It provides for either documentation of requirements for control plans prepared by the contractor or documentation of control measures required by the principal/consultant.

0173 Environmental management (AUS-SPEC)
This worksection Template is applicable to the environmental management of civil works and includes environmental controls for erosion and sedimentation, flora and fauna, groundwater, indigenous and non-indigenous heritage, traffic, water quality, air quality, waste and weeds. It provides for documentation of requirements for control plans prepared by the contractor. It provides for documenting an environmental management plan, if required, and/or the requirements for environmental management either in contractor prepared control plans or principal/consultant control measures.

0181 Adhesives, sealants and fasteners
This worksection Template is applicable to the commonly used adhesives, sealants and fasteners and provides basic defaults for projects requiring adhesives, sealants and fasteners, as part of general construction.

0183 Metals and prefinishes
This worksection Template is applicable to common metals and metal alloys, and prefinishes.

0183b Metals and prefinishes
This worksection Template is applicable to common metals and metal alloys, and prefinishes.

0184 Termite management
This worksection Template is applicable to various chemical and non-chemical systems which may be used, alone or in combination, for termite management. The various systems are located together in the one worksection as their effectiveness relies on the integration of the chosen systems. They may have impact on the Earthwork, Concrete in situ, Brick and block construction and other worksections. The core standard is AS 3660.1.

0185 Timber products, finishes and treatment
This worksection Template is applicable to the certification, durability and quality conformance of timber products. It includes preservative treatments to the AS 1604 series, moisture content and fire-resistance. State legislation will override some of the provisions of this worksection.

0191 Sundry items
This worksection Template is applicable to building components that may not obviously belong to a particular worksection or alternatively, could reasonably belong to a number of worksections. They are generally proprietary components and equipment made from a range of materials, and can be installed in a range of interior or exterior locations. Custom-made items are better located in the appropriate worksection, e.g. 0552 Metalwork – fabricated for predominantly metal items, or items to be made by a metal fabricator.

0201 Demolition
This worksection Template is applicable to demolition of existing buildings, structures and services. It includes planning and execution of the work, protection and support of adjacent structures and removal of demolished material.

0221 Site preparation
This worksection Template is applicable to site preparation requirements including existing services, site clearing, stormwater and sediment control, tree removal/protection/transplanting/maintenance, and temporary landscape fencing.

0222 Earthwork
This worksection Template is applicable to topsoil removal, excavation, filling and compaction as required for building operations. The worksection contains technical content which must be customised by a professional engineer for inclusion in a project specification.

0222q DEPW (Qld) – Earthwork
This worksection Template is applicable to topsoil removal, excavation, filling and compaction as required for building operations for DEPW (Qld). The worksection contains technical content which must be customised by a professional engineer for inclusion in a project specification.

0223 Service trenching
This worksection Template is applicable to trenching for underground services within a building site. It covers fill materials, existing services, existing surfaces, excavating, trench back fill and surface restoration.

0224 Stormwater – site
This worksection Template is applicable to stormwater drainage associated with pavements and other non-building projects. For internal stormwater piping for roof water and for simple external systems related to buildings, use 0821 Stormwater – buildings.

0224b Stormwater – site
This worksection Template is applicable to stormwater drainage mainly associated with pavements and other non-building projects or parts thereof. It overlaps with Stormwater  buildings, which should be used for internal stormwater piping for roof water and for simple external systems related to buildings. Both worksections may be used on a project according to the division of professional and/or contracting responsibility.

0241 Landscape – walling and edging
This worksection Template is applicable to retaining and free standing walls subject to height criteria conforming to local authority requirements.

0242 Landscape – fences and barriers
This worksection Template is applicable to basic fencing including picket and paling (plain paling and lap and cap) fencing, generally for domestic use; chainwire and welded mesh fencing for industrial, commercial and institutional use.

0242b Landscape – fences and barriers
This worksection Template is applicable to basic fencing including picket and paling (plain paling and lap and cap) fencing, generally for domestic use; chainwire and welded mesh fencing for industrial, commercial and institutional use.

0243 Landscape – water features
This worksection Template is applicable to self-contained water features in open landscaped areas..

0250 Landscape – combined
This worksection Template is applicable to simple ‘soft’ landscaping. It has been prepared for and is suitable only for work of a scale or size that does not warrant the use of separate worksections for each aspect of landscaping work included. As such, it combines relevant clauses from the following stand-alone landscape worksections: 0251 Landscape – soils, 0252 Landscape – natural grass surfaces, 0253 Landscape – planting, 0254 Irrigation, 0255 Landscape – plant procurement and 0256 Landscape – establishment.

0250b Landscape – combined
This worksection Template is applicable to simple ‘soft’ landscaping. It has been prepared for and is suitable only for work of a scale or size that does not warrant the use of separate worksections for each aspect of landscaping work included. As such, it combines relevant clauses from the following stand-alone landscape worksections: 0251 Landscape – soils, 0252 Landscape – natural grass surfaces, 0253 Landscape – planting, 0254 Irrigation, 0255 Landscape – plant procurement and 0256 Landscape – establishment.

0251 Landscape – soils
This worksection Template is applicable to soils for landscaping including, rock work, filling, topsoil, topsoil additives, compost and mulch. Geotechnical site investigation and soil related earthworks are also covered.

0252 Landscape – natural grass surfaces
This worksection Template is applicable to grass seeding, hydroseeding and hydromulching, turfing, stolonizing and temporary grassing.

0253 Landscape – planting
This worksection Template is applicable to composts, fertilisers, binders, mulching, planting, insect spraying, tree pruning and anchorage and is principally concerned with so-called softworks.

0254 Irrigation
This worksection Template is applicable to automatically controlled, fixed watering systems. It includes micro irrigation, drip irrigation systems, sub surface irrigation and valve boxes.

0255 Landscape – plant procurement
This worksection Template includes shrubs and ground cover as well as trees. It is structured to allow for the supply of plant material as a separate early contract or as part of the head contract.

0255b Landscape – plant procurement
This worksection Template includes shrubs and ground cover as well as trees. It is structured to allow for the supply of plant material as a separate early contract or as part of the head contract.

0256 Landscape – establishment
This worksection Template is applicable to landscape establishment and maintenance for the period between the date of practical completion and the date of final completion under the head contract.

0256b Landscape – establishment
This worksection Template is applicable to landscape establishment and maintenance for the period between the date of practical completion and the date of final completion under the head contract.

0257 Landscape – road reserves and street trees
This worksection Template includes soft landscaping works and is applicable to:

  • The vegetation of cut and fill batters, pathway verges, median areas and open drains.
  • Surface preparation, topsoiling, fertilising, and turfing or sowing of seed and may include surface protection works, hydroseeding, hydromulching and straw mulching.

The supply of plants, planting, fertilising, mulching, staking, watering and maintenance of plants including street trees.

0271 Pavement base and subbase
This worksection Template is applicable to the supply, spreading, compaction and trimming of base and subbase courses of flexible pavements for access or car parking.

0271b Pavement base and subbase
This worksection Template is applicable to the supply, spreading, compaction and trimming of base and subbase courses of flexible pavements for access or car parking.

0272 Asphalt
This worksection Template is applicable to the supply and laying of asphalt surfacing for areas not forming public roadways.

0273 Sprayed bituminous surfacing
This worksection Template is applicable to bituminous sprayed surfacing including priming, primer sealing and resealing of ancillary areas not forming public roadways.

0274 Concrete pavement
This worksection Template is applicable to the supply and placement of concrete for concrete pavements such as loading docks, carparks, landscape hard paving within site boundaries. It includes residential streets, paths and driveways.

0274b Concrete pavement
This worksection Template is applicable to the supply and placement of concrete for concrete pavements such as loading docks, carparks, landscape hard paving within site boundaries. It includes residential streets, paths and driveways.

0275 Paving – mortar and adhesive bed
This worksection Template is applicable to external paving on cement mortar or adhesive bedding on a concrete substrate using concrete, clay, natural stone and cast stone pavers, and stone setts. It is suitable for pedestrian traffic only.

0275b Paving – mortar and adhesive bed
This worksection Template is applicable to external paving in clay, stone, industrial cast stone, terrazzo and manufactured cementitious pavers on a cement mortar bed and adhesive bed to concrete substrates.

0276 Segmental pavers – sand bed
This worksection Template is applicable to the supply, placement and compaction of proprietary clay and concrete segmental paving on sand bedding for use in vehicular pavements, cycleways, footpaths and landscaped areas, over unbound base and/or subbase layer/s. This worksection does not apply to public roads and streets.

0277 Pavement ancillaries
This worksection Template is applicable to the installation of channels, kerbs, linemarking and some types of vehicle barriers.

0278 Granular surfaces
This worksection Template is applicable to the construction of granular pathways and surfaces for minor works, and includes subgrade trimming, base compaction and granular surfacing.

0279 Paving – on pedestals
This worksection Template is applicable to paving supported on pedestals on a concrete substrate using concrete, clay, natural stone and cast stone pavers. It is suitable for pedestrian traffic only.

0281 Fire access and fire trails (AUS-SPEC)
This worksection Template is applicable to the construction of perimeter tracks for bushfire protection in rural and urban developments for Crown or private land. It addresses requirements for constructing and maintaining tracks in a way that minimises soil erosion and ensures reliable access under bushfire conditions.

0282 Pathways and cycleways (Construction) (AUS-SPEC)
This worksection Template is applicable to construction of pavements for pathways and cycleways. It includes requirements for subgrade preparation and construction of subbase and base for concrete and asphalt pavements.

0292 Masonry walls (AUS-SPEC)
This worksection Template is applicable to laying of concrete, brick or stone masonry units for construction of retaining walls and free-standing walls such as noise attenuation, dwarf and feature walls for landscaping or similar structures.

0293 Crib retaining walls (AUS-SPEC)
This worksection Template is applicable to the construction of proprietary timber crib and precast concrete crib retaining walls. This may involve the design and construction of structures required to retain and reinforce soil, rock and other materials. It consists of the excavation for foundations, construction of reinforced concrete footing, precast concrete or treated timber crib wall, selected backfill in and behind the crib wall, and subsurface drainage to the wall, as documented.

0294 Gabion walls and rock filled mattresses (AUS-SPEC)
This worksection Template is applicable to the construction of gabion walls and rock filled mattresses for retaining and reinforcing soil, rock and other materials. This may involve the design. It includes excavation for foundations, subsurface drainage, backfilling behind the gabion wall, materials, assembly, erection and filling.

0310 Concrete – combined
This worksection Template is applicable to the use of concrete for building and associated structures. It is suitable for work of a scale or size which does not need a separate worksection for each of the different parts of the concrete work. It combines relevant clauses from the following worksections: Concrete formwork, Concrete reinforcement, Concrete post-tensioned, Concrete in situ and Concrete finishes. For large projects and for projects which include precast and tilt-up concrete, use separate worksections.

0311 Concrete formwork
This worksection Template is applicable to supply, installation and removal of formwork for concrete work in buildings and associated structures. It includes formwork using profiled sheeting and plywood. This worksection is generally used in conjunction with other concrete worksections.

0312 Concrete reinforcement
This worksection Template is applicable to supply and installation of fibre and steel reinforcement in concrete for buildings and associated structures. It includes ties, supports and dowelling. This worksection is generally used in conjunction with other concrete worksection.

0314 Concrete in situ
This worksection Template is applicable to concrete placement on site (in situ) for building and associated structures. It includes preparation of the base, concrete supply, placement, compaction, curing and jointing. This worksection is generally used in conjunction with other concrete worksections.

0315 Concrete finishes
This worksection Template is applicable to the production of formed and unformed finishes to concrete surfaces in building and associated structures. It covers the common surface finishes. More project specific finishes may be added, if required. This worksection should be used in conjunction with the concrete in situ worksection, in particular for curing.

0318 Shotcrete
This worksection Template is applicable to pre-mixed (wet) concrete which is applied pneumatically and compacted dynamically under high velocity. It should be used in situations where formed in situ concrete is not appropriate. This worksection is not applicable to dry mix shotcrete, or mechanically applied shotcrete used for tunnelling and mining ground support applications.

0319 Auxiliary concrete works (AUS-SPEC)
This worksection Template is applicable to the supply and placement of concrete, including sprayed concrete for concrete works of an auxiliary/supplementary nature to the primary works taking place. It includes ancillary requirements such as ground preparation, formwork and reinforcement. Auxiliary concrete works include drainage pits and other ancillary drainage structures, headwalls, wingwalls, in-situ box culverts, box culvert base slabs, retaining walls, footings, concrete safety barriers and works of a similar nature.

0321 Precast concrete
This worksection Template is applicable to precast concrete elements cast in a manufacturing plant or factory, distant from the final installation location and under quality control. Precast elements include reinforced and pre/post tensioned floors, walls, beams and columns. It includes connections, fixings and lifting accessories. Casting, transport, installation and erection procedures are in accordance with AS 3850.2. The worksection permits contractor design and is endorsed by the National Precast Concrete Association Australia (NPCAA – www.nationalprecast.com.au).

0331 Brick and block construction
This worksection Template is applicable to internal and external, load bearing and non-load bearing brick and block construction in buildings and associated structures using manufactured units comprising clay, calcium silicate, concrete or autoclaved aerated concrete (AAC) used in buildings and associated structures. It includes details on mortar, reinforcement, ties and other accessories, lintels, damp proofing and flashings.

0331b Brick and block construction
This worksection Template is applicable to internal and external, load bearing and non-load bearing brick and block construction in buildings and associated structures using manufactured units comprising clay, calcium silicate, concrete or autoclaved aerated concrete (AAC) used in buildings and associated structures. It includes details on mortar, reinforcement, ties and other accessories, lintels, damp proofing and flashings.

0332 Stone masonry
This worksection Template is applicable to natural stone masonry units used in buildings and associated structures. It includes mortar/grout, lintels, wall ties, damp proof courses and flashings and stone foundations. There is currently no Australian standard for the stone masonry product. However, the design and construction is covered in AS 3700.

0332b Stone masonry
This worksection Template is applicable to natural stone masonry units used in buildings and associated structures. It includes mortar/grout, lintels, wall ties, damp proof courses and flashings and stone foundations. There is currently no Australian standard for the stone masonry product. However, the design and construction is covered in AS 3700.

0333 Stone repair
This worksection Template is applicable to the cleaning, repair and restoration of existing stone masonry, including stone removal and replacement work. It includes requirements for natural and synthetic stones, mortars, fixings and repointing.

0342 Light steel framing
This worksection Template is applicable to framing for structures generally comprising cold formed metallic-coated or aluminium/zinc-coated steel sections where particular project specific requirements need to be met. It covers residential and low-rise floor, wall, roofing and truss framing.

0343 Tensioned membrane structures
This worksection Template is applicable to suspended tensioned membrane structures, including shade fabric cloth or waterproof membrane structures. It covers supporting structure, tension members, anchorages and foundations, both attached to other structures and stand-alone elements. The worksection is not intended to apply to proprietary structures and systems which are covered by the manufacturers details, specification and certification.

0344 Steel – hot-dip galvanized coatings
This worksection Template is applicable to post-fabrication galvanizing of fabricated structural steelwork or steel products identified as being at risk of atmospheric corrosion. The worksection derives from the standard specification for hot dip galvanized coatings published in GAA After-fabrication hot dip galvanizing by the Galvanizers Association of Australia (GAA). The worksection is endorsed by the Galvanizers Association of Australia.

0344b Steel – hot-dip galvanized coatings
This worksection Template is applicable to post-fabrication galvanizing of fabricated structural steelwork or steel products identified as being at risk of atmospheric corrosion. The worksection derives from the standard specification for hot dip galvanized coatings published in GAA After-fabrication hot dip galvanizing by the Galvanizers Association of Australia (GAA). The worksection is endorsed by the Galvanizers Association of Australia.

0345 Steel – protective paint coatings
This worksection Template is applicable to protective paint coating systems for the protection of mild steel products and structural steel against interior and exterior atmospheric corrosion. It addresses surface preparation, preparation assessment and coating application for new and maintenance work.

0345b Steel – protective paint coatings
This worksection Template is applicable to protective paint coating systems for the protection of mild steel products and structural steel against interior and exterior atmospheric corrosion. It addresses surface preparation, preparation assessment and coating application for new and maintenance work.

0361 Monolithic stabilised earth walls
This worksection Template is applicable to monolithic stabilised earth walls using a blend of 6 to 10% cement with selected low clay soils containing well graded sand and aggregates.

0362 Mud brick walls
This worksection Template applies to walls of straw-reinforced, sun-dried earth bricks/blocks (adobe), both stabilised and unstabilised. It does not address monolithic stabilised earth walls, compressed blocks (e.g. Cinva ram) or lightly-burnt blocks.

0382 Light timber framing
This worksection Template is built around the AS 1684 series, as appropriate. It is applicable to light timber framing, bracing and timber trusses in Class 1 and Class 10 buildings as defined by the BCA.

0383 Sheet flooring and decking
This worksection Template is applicable to external timber, composite or compressed fibre cement decking, and to internal sheet flooring of plywood, particleboard or compressed fibre cement as either platform floors or fitted floors. It assumes the provision of a supporting structure.

0411b Waterproofing – external and tanking
This worksection Template is applicable to tanking and membrane applications to roofing, balconies, concrete slabs over below ground spaces and planter boxes and tanking. It relies on AS 4654.1 and AS 4654.2. It does not include concrete mixtures, penetrant sealers or decorative coatings.

0421 Roofing – combined
This worksection Template is applicable to the provision of roof coverings of profiled sheet metal, tiles, slate, fibre cement, shingles and shakes, seamed sheet metal, and roof plumbing.

0431 Cladding – combined
This worksection Template is applicable to lightweight external wall cladding for work of a scale or size which does not warrant the use of separate worksections for each selected cladding type. It combines relevant clauses from 0434 Cladding – flat sheets and panels, 0435 Cladding – planks and weatherboards, 0436 Cladding – profiled and seamed sheet metal and 0437 Cladding – insulated panel systems.

0431b Cladding – combined
This worksection Template is applicable to lightweight external wall cladding for work of a scale or size which does not warrant the use of separate worksections for each selected cladding type. It combines relevant clauses from the Cladding – panels, Cladding – planks, Cladding – profiled sheet metal and Cladding – sheet and pre-assembled systems worksections.

0433 Stone cladding
This worksection Template is applicable to mechanically fixed natural stone or cast stone cladding panels in external or internal applications.

0463 Glass blockwork
This worksection Template is applicable to fully framed glass blockwork with mortar joints.

0551 Joinery
This worksection Template is applicable to the shop fabrication and site installation of custom made joinery fixtures and trim to walls and openings.

0551b Joinery
This worksection Template is applicable to the shop fabrication and site installation of custom made joinery fixtures and trim to walls and openings.

0552 Metalwork – fabricated
This worksection Template is applicable to what is generally known as custom built architectural metalwork such as stairs, ladders, walkways, balustrading, handrails, screens, guards, bollards, furniture, and decorative items.

0552b Metalwork – fabricated
This worksection Template is applicable to what is generally known as custom built architectural metalwork such as stairs, ladders, walkways, balustrading, handrails, screens, guards, bollards, furniture, and decorative items.

0573 Fire extinguishers and blankets
This worksection Template is applicable to fire extinguishers and fire blankets. Products used must be on the ActivFire Register of Fire Protection Equipment. The specification should reflect any extra requirements of local statutory authorities. The principal product standards are the AS/NZS 1841 series and AS 2444.

0581 Signage
This worksection Template is applicable to house signage, display and statutory signs. Signage for switchboards, piping, etc. should be dealt with in the appropriate technical worksection, but coordinated with this worksection.

0581b Signage
This worksection Template is applicable to house signage, display and statutory signs. Signage for switchboards, piping, etc. should be dealt with in the appropriate technical worksection, but coordinated with this worksection.

0611 Rendering and plastering
This worksection Template is applicable to traditional wet plastering and rendering, though proprietary and special systems may feature in the project specifications and drawings. It includes work on lath, and on panelling of various materials.

0612 Cementitious toppings
This worksection Template is applicable to cement-based toppings on floors and steps. There is no relevant standard in Australia but there are numerous guides available from BRANZ and the Cement and Concrete Association.

0612b Cementitious toppings
This worksection Template is applicable to cement-based toppings on floors and steps. There is no relevant standard in Australia but there are numerous guides available from BRANZ and the Cement and Concrete Association.

0613 Terrazzo in situ
This worksection Template is applicable to in situ cementitious terrazzo floor systems. There is no relevant standard.

0632 Stone and terrazzo tiling
This worksection Template is applicable to stone tiling, industrial cast stone tiling, terrazzo tiling (cementitious and resinous) and manufactured cementitious tiling on various substrates.

0641 Applied wall finishes
This worksection Template is applicable to custom made wall panels, in situ applied wall linings and the in situ application of specialist wall finishes. There are no published standards, Australian or otherwise, for the specialist finishes utilised by interior designers.

0651 Resilient finishes
This worksection Template is applicable to resilient sheet and tile finishes with associated underlay including cork tiles, linoleum, corklinoleum, rubber, polyvinyl chloride (PVC), flexible terrazzo tiles and static control flooring. It also includes synthetic sporting surfaces.

0656 Floor sanding and finishing
This worksection Template is applicable to basic floor sanding of timber substrates for other finishes, basic floor sanding as the first stage preparation for clear coating systems, finish sanding for clear coating systems and the selection and application of clear coating systems.

0671 Painting
This worksection Template is applicable to the in situ application of coating films to buildings and interior elements. The primary referenced standard is AS/NZS 2311, a guide to products and procedures for the painting of buildings for domestic, commercial and industrial use.

0671b Painting
This worksection Template is applicable to the in situ application of coating films to buildings and interior elements. The primary referenced standard is AS/NZS 2311, a guide to products and procedures for the painting of buildings for domestic, commercial and industrial use.

0672 Textured and membrane coatings
This worksection Template is applicable to the in situ application of latex extensible (membrane) coating and textured surface coating systems to buildings and interior elements. The primary referenced standard is AS/NZS 2311 which provides a guide to products and procedures for the painting of buildings for general domestic, commercial and industrial use.

0673 Powder coatings
This worksection Template is applicable to the off-site application of powder coating systems to aluminium architectural applications, and to exterior and interior buildings elements. The primary referenced standards are AS 3715 for aluminium and aluminium alloy substrates and AS 4506 for metal substrates other than aluminium.

0702 Mechanical design and install
This worksection Template is applicable to simple mechanical installations that are to be designed and installed by the contractor.



0802 Hydraulic design and install
This worksection Template is applicable to simple hydraulic installations for which the specification will be prepared by the architect because the principal has not engaged a specialist hydraulic consultant, the hydraulic design will be done by the contractor. It deals with hot and cold water services, sanitary plumbing and drainage, stormwater, rainwater storage systems, grey water systems, natural gas, LP gas and fire services installations.

0811s Sanitary fixtures
This worksection Template is applicable to the selection and installation of sanitary fixtures. It incorporates design for access and mobility standards AS 1428.1, AS 1428.2 and AS 1428.3 as well as the standards listed in the WaterMark Product Database.

0812s Tapware
This worksection Template is applicable to taps and tapware and includes related fittings such as towel rails.

0902 Electrical design and install
This worksection Template is applicable to simple electrical services installations, in which the specification will be prepared by the architect, without the involvement of a specialist electrical consultant, and the electrical design will be undertaken by the contractor. It includes a summary of the systems and design parameters relating to the electrical installation.

1102 Control of erosion and sedimentation (Construction)
This worksection Template is applicable to the control of erosion and sedimentation in conformance with an approved Erosion and sediment control plan (ESCP). It provides for either documentation of requirements for control plans prepared by the contractor or documentation of control measures by principal/consultant. It includes both temporary and permanent erosion and sediment control measures.

1111 Clearing and grubbing
This worksection Template is applicable to the clearing, grubbing and removal of all vegetation, logs, stumps, boulders, roots, scrub, debris and dumped material to allow site works for roadway construction. Demolition and disposal of any minor man-made structures (such as fences and livestock yards). Removal of all rubbish and other materials that are unsuitable for use in the works.

1391 Service conduits
This worksection Template is applicable to the supply of material and the underground installation of electrical, telecommunications and irrigation conduits and pits. This worksection does not include trenching, excavation or backfill which is included in 1152 Road openings and restoration (utilities).

1392 Trenchless conduit installations
This worksection Template is applicable to the method of installation of any type of drainage or service conduit where trenchless techniques are required. Trenchless techniques minimise interference with existing features, facilities or traffic. These techniques may be by either jacking, ramming, bursting, thrust or auger boring, micro-tunnelling, directional drilling or other suitable techniques as appropriate for the particular installation.

1401 General requirements – parks and open space (Maintenance)
This worksection Template is applicable to the general requirements of the Principal for parks and open space maintenance contracts. It includes plan requirements, contract period, work by others, environmental protection, emergency response, accidents, damage, measurement and payment.

1402 Maintenance schedules – parks and open space
This worksection outlines the contract schedules for parks and recreation areas, bills of quantities and shedules of dayworks rates.

1403 Parks and open space maintenance plan (PMP)
This worksection Template is applicable to the Parks and open space Maintenance Plan (PMP) required under 1401 General requirements – parks and open space (Maintenance). The PMP is a contract specific document which is confirmation of the understanding and commitment of the Contractor and the Principal on maintenance performance policy, maintenance organisation, Activity Specifications, management procedures and maintenance planning. The Annexures to the PMP also include sample non-conformance management forms, Damage forms and Contractor Records.

1404 Annexures to parks and open space maintenance plan
This worksection Template is applicable to proformas and sample forms for the management of parks and open space maintenance contracts. Use these proformas in conjunction with 1403 Parks and open space maintenance plan.

1415 Weed control
This worksection covers the spraying of herbicide or related treatment such as hand weeding and hot water or direct chemical application to provide a weed free surface area to parks and recreation areas, gardens, around park/area furniture and along boundary fences for which the council is responsible.

1416 Planting of annuals and trees
This worksection include the removal of spent annual plants, preparation of beds and planting out and watering the new annuals in garden areas provided in councils’ parks and recreation areas. It also includes the planting of replacement trees in councils’ parks and recreation areas.

1417 Care of trees and shrubs
This worksection will include the care of trees and shrubs including significant trees, tree bases and tree establishment. It also covers trimming of growth on trees and shrubs in parks and recreation areas including provision of minimum clearances for both roadways and footways.

1418 Gardens
This worksection includes the inspection and maintenance of gardens, excluding annual plants, in areas provided in councils’ parks and recreation areas.

1419 Care of trees and turf
This worksection covers watering, fertilising, soil aeration, thatch removal and top-dressing of parks and recreation areas.

1420 Grass mowing
This worksection covers mowing of all classifications of parks and recreation areas and those areas classified by council as grassed areas. It also includes edge trimming along footpath edges, around trees, shrubs, access chambers, hydrants, post, poles, under and around seat and tables.

1421 Native bushland
This worksection includes the inspection and maintenance of native bushland in councils’ parks and recreation areas in accordance with councils’ bushland management plan. The major work will be consolidation and long-term weeding following the primary weeding carried out in council’s bush regeneration programme. Planting of native and indigenous species and protective fencing of sensitive areas are activities provided external to this maintenance activity.

1422 Dunal areas
This worksection covers the special maintenance acivity related to the stabilisation and preservation of areas predominated by sand dune terrain. The activity includes inspection and maintenance of board and chain walkways, fencing and plantings.

1423 Pest control
This worksection covers the spraying of pesticide or related treatment such as direct chemcial application to provide and insect/pest free surface area to parks and recreation areas, gardens, around park/area furniture and along boundary fences for which the council is responsible.

1431 Footpath paving repairs
This worksection covers the inspection and maintenance of concrete and segmental paver footpaths located in parks and recreation areas. It includes paths for shared or sole-use by bicycles. For inspection and conditional assessment of footpaths use IPWEA Practice Note 1 Footpaths and cycleways. The activity includes the removal of any footpath defects which could constitute a safety hazard to park and recreation area users. Litter Collection from footpaths is covered in the 1491 Open space litter collection worksection.

1432 Gravel footpath repairs
This worksection covers the inspection and maintenance of gravel footpaths located in parks recreation areas. Gravel paths include footpaths and shared or sole use bicycle pathways and include crushed rock, pebbles, sand or compacted gravel surfacing. This activity includes restoration of the surface quality and associated minor work provide for the ongoing functionality of the surface.

1433 Footpath and kerb ramp repairs
This worksection covers the inspection and maintenance of all footpaths and kerb ramps located adjacent to the carriageway. Carry out inspections and conditional assessment of footpaths in accordance with IPWEA Practice Note 1 and Practice Note 2 for footpaths and kerbs and channels. The activity includes the repair of any damaged kerb ramps and removal of any footpath defects, which could constitute a safety hazard to pedestrians. Control of vegetation on footpaths is covered in the 1413 Tree and vegetation control in road reserves worksection. Litter Collection from footpaths is covered in the 1491 Open space litter collection worksection.

1434 Bushfire perimeter track repairs
This worksection covers the inspection and maintenance of bushfire perimeter tracks located in the asset protection zone. This activity includes restoration of the surface quality and associated minor works to provide for the ongoing functionality of the surface as defined in the Councils Bushfire risk management plan.

1441 Bituminous surfacing repairs
This worksection covers the repair of pavement surfacing on footpaths, car parks or driveways by several techniques. Surfacing is defined as the wearing course only. The work may utilise hot asphalt or coldmix but shall more typically comprise bitumen emulsion sealing with fine aggregate.

1442 Boat ramps
This worksection covers the inspection and maintenance of recreational boat ramps located in bays, rivers or lakes, both tidal and non-tidal.

1461 Swimming enclosures
This worksection covers the inspection and maintenance of swimming enclosures located in bays, rivers, lakes or ocean, both tidal and non-tidal, including rock or constructed pools at coastal locations refreshed by tidal action. The activity excludes purpose built olympic pools in council parks and leisure centres.

1462 Boundary fence repair
This worksection covers the inspection of all boundary fences, gates and access points in parks and recreation areas. It includes monitoring possible future problems, i.e. intrusion by extended tree or shrub growth, and poor foundations. Replacements of fencing components to an approved work plan will be paid under the conditions of a work order.

1471 Barbecues
This worksection covers the maintenance of outdoor electrical, or liquefied petroleum (LP) gas, barbecues situated in council parks and recreation areas.

1472 Drinking fountains
This worksection covers the maintenance of drinking fountains (bubblers) located in council’s parks and recreation areas.

1473 Barriers
This worksection covers the inspection and maintenance (including painting/oiling) of fences, handrails, bicycle racks, vehicle barriers, tree and garden guards, and similar items to ensure that they continue to provide the function for which they were installed. It includes the containment fences at lookouts and playgrounds and containment and catch fences at sportsgrounds.

1474 Lighting
This worksection covers the inspection and maintenance of lighting systems, electrical or solar power, installed in public parks and recreation areas. It includes lighting for sportsgrounds, carparks and pedestrian areas.

1475 Playground equipment
This worksection covers the maintenance of playground equipment and exercise stations in public parks and recreation areas in accordance with the maintenance requirements of AS/NZS 4486.1.

1476 Park furniture
This worksection covers the inspection and maintenance of park furniture such as seats, tables, shelters, gazebos, bollards, signs, plaques in parks and recreation areas to ensure that they continue to provide the function for which they were installed.

1477 Sportground facilities
This worksection includes the maintenance, installation and removal of equipment and apparatus required for the conduct of sports activities for each particular sportsground. Included are goal posts, goal and catch nets, track and field athletics equipment and apparatus, cricket sight screens, pitches and mats, sports linemarking and the maintenance of synthetic grass surfaces.

1478 Public art
This worksection covers the inspection and reporting on the condition of miscellaneous public art works including statutes, sculptures, memorials and fountains located in Councils parks and recreation areas.

1481 Accident repairs (Recoverable)
This worksection covers inspection and appraisal of damage, compilation of details and reporting related to accidents where costs are recoverable.

1482 Accident repairs (Non-recoverable)
This worksection covers inspection and appraisal of damage, compilation of details and reporting related to accidents or vandalism where costs are non-recoverable.

1483 Emergency call out
This worksection is a template for recording actions taken in response to an emergency call out. It provides for indicating any costs that may be recoverable in respect of public safety. Performance requirements are also set out.

1484 Storm damage response
This worksection covers short notice repairs under emergency conditions concerned with making the park or recreation area safe. It is limited to activity which could reasonably be undertaken in a 24 hour period. Work includes removal of debris, causing obstruction or damage to the adjacent property, or park/area furniture. The cause of the storm damage may be due to the action of wind, rain, flood or lightning strike. This may include the use of tree pruning contractors, cherry pickers, chainsaws, trucks and the like. It may also include provision or repairs to scours or erosion so as to make the park or recreation area safe.

1491 Open spaces litter collection
This worksection covers all park and recreation area litter collection (including removal of dead animals) and emptying of litter bins. It includes the proper disposal of the litter clear of the park or recreation area either by recycling or legal tipping. It includes the provision of plastic bag liners to all litter bins and dog bag dispensers.

1492 Open space graffiti removal
This worksection includes the identification and removal of any graffiti on council property that is visible to the public.

1493 Beach cleaning
This activity includes raking and sieving of beaches by mechanical means and by manual cleaning where areas are not accessible by mechanical cleaning equipment. The activity also includes the disposal of the collected debris either by recycling or legal tipping.

1501 General requirements – building and facility (Maintenance)
This worksection Template is applicable to the general requirements of the Principal for building and facility maintenance contracts. It includes plan requirements, contract period, work by others, environmental protection, emergency response, accidents, damage, measurement and payment.

1502 Maintenance schedules – building and facility
This worksection outlines the contract schedules for routine general maintenance, building and facilities data sheet, activity frequency schedule, schedule of lump sum components, bills of quantities, schedules of dayworks rates.

1503 Building and facility maintenance plan (BFMP)
This worksection Template is applicable to the Building and Facility Maintenance Plan (BFMP) required under 1501 General requirements – building and facility (Maintenance). The BFMP is a contract specific document which is confirmation of the understanding and commitment of the Contractor and the Principal on maintenance performance policy, maintenance organisation, Activity Specifications, management procedures and maintenance planning.

1504 Annexures to the building and facility maintenance plan (BFMP)
This worksection Template is applicable to proformas and sample forms for the management of building and facility maintenance contracts. Use these proformas in conjunction with 1503 Buildings and facility maintenance plan.

1601 General requirements – road reserve (Maintenance)
This worksection Template is applicable to the general requirements of the Principal for road reserve maintenance contracts. It includes plan requirements, contract period, work by others, traffic management, environmental protection, emergency response, accidents, damage, measurement and payment.

1602 Maintenance schedules – road reserve
This worksection is a spreadsheet and includes 10 worksheets for work cost review, bitumen reseals, seal preservation, proposed construction, road reserve assets, gravel pit testing, gravel resheeting, schedule of rates and samples for plant hire and labour rates.

1603 Road reserve maintenance plan (RMP)
This worksection Template is applicable to the Road reserve Maintenance Plan (RMP) required under 1601 General requirements – road reserve (Maintenance). The RMP is a contract specific document which is confirmation of the understanding and commitment of the Contractor and the Principal on maintenance performance policy, maintenance organisation, Activity Specifications, management procedures and maintenance planning. The RMP also includes sample non-conformance management forms, Damage forms and Contractor Records.

1604 Annexures to road reserve maintenance (RMP)
The following worksection Template is applicable to proformas and sample forms for the management of road reserve maintenance contracts. Use these proformas in conjunction with 1603 Road reserve maintenance plan.

1671 Road reserve boundary fence repairs
This worksection covers the inspection of all fence and access points on the road reserve network. it includes monitoring possible future problems i.e. intrusion by extended tree or shrub growth and also monitoring of locations that are regularly damaged on a more frequent basis, such as school location etc.

1672 Road reserve fences and handrails
This worksection covers the inspection and maintenance, including painting, of median and pedestrian fences and handrails to ensure that the fences and handrails continue to provide the function for which they were installed. It includes the fences at pedestrian crossings and at school crossings.

1673 Street seats and bus shelters
This worksection covers the inspection and maintenance of street seats and bus shelters to ensure that they continue to provide the function for which they were installed.

1701 Wharves and decks maintenance
This activity covers the inspection and maintenance (including painting/oiling) of wharves and decks, including jetties, fishing and viewing decks, boardwalks, mangrove walkways, lookouts and similar structures to ensure that they continue to provide the function for which they were installed. It includes structures that are situated in water or on land.

1841 Water supply – irrigation systems
This worksection covers the maintenance of irrigation systems equipment in public parks, sportsgrounds, gardens and recreation areas.

1851 Clear open space drains
This worksection covers all unlined open drains, catch drains, spoon drains, table drains and waterways in parks and recreation areas. Low flow channels, table drains and catch drains, if grassed are to be mowed during the mowing program. Table drains are to be graded as required to remove obstructions. Watercourses may require maintenance to remove or control silt or scour.

1852 Clear open space drainage culverts
This worksection covers the clearing of all stormwater drainage structures located in parks or recreation areas including the public car parking areas. These include all types, such as extended kerb inlets with or without grate, side entry pits and gully pits, connections from inlets to the main drain, culverts and energy dissipators.

1854 Minor repair of lined drains in road reserves
This worksection covers the inspection, repair and maintenance of all lined drains. These include concrete, stone pitched drains, drains permanently protected by geotextile or similar material and drains lined with galvanized corrugated iron units. Work includes repair of scour or subsidence as well as the clearing of siltation or vegetation effecting the efficiency of the drain.
